The “Design Basis” icon located on the toolbar allows the designer to select material properties and design codes for all elements in a structure at one time without having to redefine them for each element (such as lintels, shear walls and columns). The reinforcement location is specified by the user and may be off-center when an increase in effective depth is desired, such as for retaining wall construction.
The software is limited to hollow unit masonry in single wythe construction, but the masonry can be fully or partially grouted (including ungrouted), and reinforcement may be included within grouted cells.
#Concrete design software free download archive
Finally, printable documentation is provided for inclusion in design calculations that may be submitted to building officials or to archive designs. Note that although dual units are shown in the text of this TEK, the software itself uses inch-pound units only. In the latter case, load combinations are calculated at very small intervals along the wall, and the critical design forces are determined and reported. The engineer may specify the critical design forces or may choose to have them calculated from specified design loads, boundary conditions and dimensions. 6, 7) for information on these design methods. See Strength Design Provisions for Concrete Masonry, TEK 14-4B, and Allowable Stress Design of Concrete Masonry, TEK 14-7B, (refs. The software also includes Alternative Basic Load Combinations that permit the use of the one-third stress increase in allowable stress design per the IBC.
#Concrete design software free download code
Both concrete and clay masonry elements can be designed using either allowable stress design (ASD) or strength design (SD) using various editions of Building Code Requirements for Masonry Structures (MSJC) (1995, 1999, 2002, 2005 or 2008) and the International Building Code (IBC) (2000, 2003, 2006 or 2009) (refs. The software includes the design of walls loaded out-of-plane, walls loaded in-plane (shear walls), masonry and precast concrete lintels, and columns. This TEK describes the capabilities of Version 5.0 of Structural Masonry Design System software (ref. Software allows the design professional to quickly determine designs that work and therefore optimize solutions. Structural design of masonry can be tedious and complex.
